Himiway Big Dog 750W Long Range Electric Cargo Bike

Himiway Big Dog, with its powerful 750W gear motor and specialized inner ring, is considered a premium version of the Escape. The rear rack can carry cargo of all shapes and sizes, easily helping you solve the trouble of going out with heavy equipment. Big Dog’s brushless gear hub motor can help you conquer any obstacle in your chosen terrain. Compared with Escape, an upgraded battery is worth mentioning, which combined with Samsung and LG Lithium-ion Battery can last 7 hours for one full charge. It should be the perfect choice when you plan for long-distance travel.

Your fully loaded sidekick

• Sturdy Rear Rack
• Smooth Ride
• Twist Throttle
• 7 Speed Gear Shift System
• Multifunctional Display

Diverse, Large, Multifunctional Rear Racks

This Cargo Bike is perfect for taking the kids across town or loading up at the hardware store. The electric cargo bike's sturdy, multifunctional rear rackand lower center of gravity provide stable, reliable rides, even when you’re taking full advantage of the 400 lb. Max out the Big Dog's impressive 400lb. payload capacity by strapping on bulky items, attaching panniers, platforms, or baskets. Maneuver easily - even when loaded up! Our in-house team of engineers kept a low center of gravity for balanced, stable rides.

Updated Motor : Fast acceleration & Good Gradeability & Longer Lifespan

The Big Dog’s motor uses an updated 750W Upgraded Brushless Geared Hub Motor and specialized inner ring, which enables high-temperature resistance and better heat dissipation. This inner ring reduces the motor magnets’ attenuation speed, which guarantees longer life expectancy for the motor, meaning your Himiway Big Dog will outlast the competition where it matters most—the power system. Big Dog’s brushless geared hub motor will help you conquer any obstacle in your chosen terrain.

Superior Battery: Smaller Size & Longer Range & Shorter Charging Time

Himiway Big Dog combines the new 48V 20Ah Samsung/LG battery technology with a 5000mAh single cell capacity—smaller size but larger diversity. Compared with 3500mAh cells made of nickel, cobalt, and manganese, this 960Wh battery efficiently improves the range, stability, and safety of Himiway bikes. A single charge can last up to 60 miles on pure electric power and over 80+ miles with pedal assist. The battery will maintain 80% capacity after 1000 charges. The integrated battery design helps maintain capacity and can reduce mechanical failures in even the most extreme weather conditions by up to 95%.

Please note: There are safety risks in modifying e-bikes and replacing battery chargers. It is recommended that you do not do so or operate under the guidance of professional personnel.

LCD Display

Backlight display provides the information of speed, mileage, power, etc.

Specification
Battery 48V 20Ah Samsung/LG lithium battery
Range 60–80miles
Hub Motor 750W brushless gear motor
Total Payload Capacity 400 lb.
Recommended Rider Heights5'1" ~ 6'5"
Charger US standard 3.0 A smart charger
Controller 48V/22A
Display LCD display with USB charging
Weight 79 lb.
Pedal Assist Intelligent 0~5 level pedal assist

Components
Tires 20″ x 4″ Kenda fat tires
Brake lever Aluminum alloy comfort grip levers with motor cutoff switch
Rear Light Integrated tail light
Freewheel Shimano 7 speed gear shift system
Brake180mm mechanical disc brakes
Chain KMC chain
Stem MA-5040 28.6*31.8MM
Crank 46T*170MM 4-jaw L/R forged alloy
Gearing Shimano- 14-28T BROWN/BK
Front Fork Alloy front suspension fork with lockout and adjustment
Throttle Half twist throttle
Pedal Alloy pedal with reflectors
Bike Frame Upgraded 6061 Aluminum frame
Front Light 48V LED light
Saddle SR saddle
Seat Post 34*350mm Alloy Seatpost
Kickstand Heavy-duty aluminum
Spokes Alloy Wheels

Geometry
A – Total Length 70
B – Handlebar Height 43
C – Wheelbase 46.4
D – Minimum Seat Height 27.6
E – Maximum Seat Height 35.4
F – Chain Stay Length 17.5
G – Standover Height 16.5
H – Top Tube Length 25.2
I – Wheel Diameter 23.2
J – Head Tube Length 8.3
K – Handlebar Length 27.6
